All-In-One High Power 0-120V Charger

Features

• Multifunction Fast Battery Charger Trickle Charger Smart Charger&Maintainer with 0-60V/0-120V Adjustable Current and Voltage for 12V, 12.8V, 14.6V, 24V, 36V, 48V, 60V, 72V, 96V, 120V LiFePO4 Lithium-Iron Deep Cycle Rechargeable Batteries & Battery Desulfator

• It is a lightweight, high-frequency type charger for charging 12V(12.8V) LiFePo4 batteries made with Lithium Iron Phosphate cells.

• Applications: RVs, Commercial Vehicles, Boats, Yachts, Cars, Solar Battery, Motorcycly Battery and many more!

• Warranty: 12 Months

• Please Note: For the normal use of the charger, please do not connect the charging device before adjusting the voltage.

• Do not adjust the voltage during use, so as not to burn the host, and the consequences will be at your own risk.

Warning:

For the normal use of the charger, please do not connect the charging device before adjusting the voltage.
Do not adjust the voltage during use, so as not to burn the host, and the consequences will be at your own risk.

Note: (important things are repeated three times!) The positive and negative poles of the battery cannot be reversed (red positive +; black – ) is a negative number. Reverse connection will cause damage (damage is not guaranteed).

Specifications:

Input voltage: AC 100V –240V

Input power: 2.6-60V0-50A/0-120V0-25A(When the input AC power is 110V. The total output power of the charger is 1500W. When the AC power is 220V, the total output power of the charger is 3000W)

Output voltage: DC constant voltage meets 2.6V-60V/120V (1S to 3S Li-ion Lipo and 1S to 4S Lifepo4)

120V25A output current: DC constant current 1-25A adjustable.

60V50A output current: terminal supports 30A (XT90 supports 50A)

Output dimensions: 350X90X190 (mm) (60V/120V)

Cooling method: air cooling

Accessories host / power cord (European standard), American standard optional) / clip (optional) / Anderson (optional) Note: (important things are repeated three times!) The positive and negative poles of the battery cannot be reversed (red positive + + ; black negative -). Reverse connection will cause damage (damage is not guaranteed).

Remark: The input AC voltage of the United States, Canada, and Japan is 110V, so the total power of the charger is only 1500W. When selecting a voltage of 60V. The maximum current can only be adjusted to 25A.

All In One Charger

Perfect for Lifepo4 batteries, limited for lead acid and lithium batteries

Safety & High Power Performance

Multiple protections for safe using

Battery Back to Life

Fast charger, adjustable voltage and current, suitable for 12V, 14.6V, 24V, 36V, 48V batteries

Adjustable Voltage and Current Setting

All-in-one button control: voltage, current, power, mode etc.

Large LCD Smart Digital Display

All-in-one button control: voltage, current, power, mode etc.

Thermal Compensation

Good performance in winter weather and summer weather

Full Accessories Available

Anderson, clip connect lines are available.
